DYNAPAC CA3500 Vibratory Roller Parts Catalog Manual 4812160190_B PDF DOWNLOAD
FILE DETAILS:
DYNAPAC CA3500 Vibratory Roller Parts Catalog Manual 4812160190_B PDF DOWNLOAD
Language : English
Pages : 620
Downloadable : Yes
File Type : PDF
TABLE OF CONTENTS:
DYNAPAC CA3500 Vibratory Roller Parts Catalog Manual 4812160190_B PDF DOWNLOAD
CA3500D/PD s/n 10000146xxA012823 – 019417
Engine: Cummins QSB 4.5 (IIIB/T4i)
CA3500D/PD (IIIB/T4i) SN 10000146xxA012823 – 019417 1
Service kits
4812156993 Service kit, 50h Plus 3
4812159996 Service kit, 50h Plus Limited slip Rear axle 5
4812158687 Service kit, 500h Plus Cummins QSB 4.5 7
4812158688 Service kit, 500h Cummins QSB 4.5 9
4812158689 Service kit, 1000h Plus Cummins QSB 4.5 11
4812158690 Service kit, 1000h Cummins QSB 4.5 13
4812158691 Start up kit Cummins QSB 4.5 15
4812158692 Service kit, 2000h Plus Cummins QSB 4.5 17
4812158693 Service kit, 2000h Cummins QSB 4.5 19
Repair kits
Eccentric shaft kit 21
4812157275 Drum rotation kit 23
4812158579 Shock absorber kit, drum 25
General – Keys and others
Fuses 27
Keys 29
Frame
Frame, front 31
Steering hitch, To A016994 excl. A016413, A016416 and A016497
4812117507 Steering hitch, cpl 33
Steering hitch, From A016995 incl. A016413, A016416 and A016497
Steering hitch module 35
4812114990 Steering hitch, cpl 37
Scrapers, option
Scrapers, option 39
Scraper module Steel 41
Scraper module Rubber 43
Scraper assy 45
Scraper module PD 47
Scraper module PD Heavy duty 49
Scraper mount 51
Frame, rear 53
Frame, rear 55
Cover assembly 57
Step module 59
Step assy 61
Tool box module, Option 63
Engine structure 65
Engine hood 67
4812120749 Engine hood, cpl
4812120749 Engine hood, cpl 69
4812118994 Lock handle, cpl 71
Fender module 73
Hinge module 75
Lock handle assy 77
Gas spring module 79
Safety link module 81
Drum
Drum, cpl 83
4812113266 Drum gear 87
Vibration motor adapter 89
Tooth wheel module 91
Drum cartridges (D-version)
4812158089 Drum cartridge, vibration side (D version) 93
4812158092 Drum cartridge, vibration side (D version) 95
4812158094 Drum cartridge with shaft nut, vibration side (D version) 97
4812158097 Drum cartridge with shaft nut, vibration side (D verison) 99
4812158084 Drum cartridge, drive side (D version) 101
4812158087 Drum cartridge, drive side (D version) 103
Drum cartridges (PD-version)
4812158090 Drum cartridge, vibration side (PD version) 105
4812158093 Drum cartridge, vibration side (PD version) 107
4812158095 Drum cartridge with shaft nut, vibration side (PD version) 109
4812158098 Drum cartridge with shaft nut, vibration side (PD version) 111
4812158085 Drum cartridge, drive side (PD version) 113
4812158088 Drum cartridge, drive side (PD version) 115
Pad shell, option 117
Engine
Engine 119
Diesel engine 123
Belt guard module 125
Bracket module 127
Cooling system 129
Cooler stand module 131
Hose assy kit 133
Air cleaner 135
Air cleaner module 137
Fuel system
Fuel system 139
Fuel hoses 141
Fuel tank module 143
Fuel tank 145
Brackets assy 147
Draining module 149
Exhaust system 151
Expansion tank assembly 153
Transmission
Rear axle and wheels 155
4812113344 Rear axle, limited slip
4812113344 Rear axle, limited slip 157
Differential & Bevel gear 159
Brakes 161
Hub reduction 163
4812113341 Rear axle No spin
4812113341 Rear axle No spin 165
Differential 167
Central housing and brakes 169
Hub reduction 171
Hydraulic system
Hydraulic system, drum Traction control
Hydraulic system, drum Traction control 173
Hydraulic motor module, vibration 175
4812112216 Hydraulic motor, vibration
4812112216 Hydraulic motor, vibration 177
Rotary group 179
Flush & boost pressure valve with orifice 181
Cover 183
Hydraulic motor 185
4812112215 Hydraulic motor
4812112215 Hydraulic motor 187
Rotary group 189
Flush and boost pressure valve 191
Cover with shaft seal ring 193
Hydraulic motor 195
4812112200 Hydraulic motor
4812112200 Hydraulic motor 197
Loop flushing 201
Hydraulic system, drum Anti-spin system
Hydraulic system, drum Anti-spin system 203
Hydraulic motor module, vibration See page 175
4812112216 Hydraulic motor, vibration
4812112216 Hydraulic motor, vibration See page 177
Rotary group See page 179
Flush & boost pressure valve with orifice See page 181
Cover See page 183
Hydraulic motor See page 185
4812112215 Hydraulic motor
4812112215 Hydraulic motor See page 187
Rotary group See page 189
Flush and boost pressure valve See page 191
Cover with shaft seal ring See page 193
Hydraulic motor 205
4812112202 Drum motor
4812112202 Drum motor 207
Drum motor. Front section 209
Loop flushing 211
Drum motor. Rear section 213
Hydraulic system, rear axle Traction control, limited slip
Hydraulic system, rear axle Traction control, limited slip 215
Hose holder 217
Hydraulic motor 219
4812112208 Rear axle motor
4812112208 Rear axle motor 221
Front section 223
Rear section 225
Hydraulic system, rear axle Traction control, no slip
Hydraulic system, rear axle Traction control, no slip 227
Hose holder See page 217
Hydraulic motor 229
4812112211 Rear axle motor
4812112211 Rear axle motor 231
Loop flusing 235
4812122932 Hydraulic motor 237
Hydraulic system, rear axle Anti-spin system
Hydraulic system, rear axle Anti-spin system 241
Hose holder See page 217
Hydraulic motor 243
4812112210 Rear axle motor
4812112210 Rear axle motor 245
Front section 247
Rear section 251
Hydraulic system, rear axle Dual speed
Hydraulic system, rear axle Dual speed 253
Hose holder See page 217
Hydraulic motor 255
4812112207 Axle motor 257
Hydraulic system, oil tank
Hydraulic system, oil tank 261
Hydraulic oil tank assembly 263
Connector assy 267
Hydraulic valve module 269
4812120840 Hydraulic valve 271
4812112238 Hydraulic valve 273
Fan module, front 275
4812117797 Hydraulic motor 277
Fan module, rear 279
4812117796 Hydraulic motor 281
Hydraulic system, engine room
Hydraulic system, engine room 283
Hydraulic pump module 285
Hydraulic pump module 287
4812112170 Hydraulic pump, propul pump
4812112170 Hydraulic pump, propul pump 289
Front section 291
Rear section 293
Hydraulic oil filter assy 297
Hydraulic pump module 299
4812118150 Hydraulic pump, steering 301
Hydraulic system, engine room Adjustable frequency, eco opti
Hydraulic system, engine room Adjustable frequency, eco opti 303
Hydraulic oil filter assy See page 297
Hydraulic pump module See page 287
4812112170 Hydraulic pump, propul pump
4812112170 Hydraulic pump, propul pump See page 289
Front section See page 291
Rear section See page 293
Hydraulic pump 305
4812112180 Hydraulic pump 307
Hydraulic pump module See page 299
4812118150 Hydraulic pump, steering See page 301
Hydraulic pump module, Eco 309
4812118151 Hydraulic pump 311
Hydraulic system, frame rear
Hydraulic system, frame rear 313
Connector kit 315
Connector kit 317
Hydraulic system, steering
Hydraulic system, steering 319
Hydraulic cylinder 321
4812121946 Hydraulic cylinder 323
Hydraulic cylinder 325
Steering valve module 327
Hydraulic hoses, steering 329
Hydraulic system, emergency steering
Hydraulic system, emergency steering 331
4812112188 Hydraulic pump Emergency steering unit 333
4812112236 Hydraulic valve 335
Electric equipment
Electric cables, power supply, 1-pole
Electric cables, power supply, 1-pole 337
Battery module 339
Battery disconnector module 341
Electric cables, power supply, 2-pole, option
Electric cables, power supply, 2-pole, option 343
Battery module See page 339
Battery disconnector, 2-pole 345
Electrical cables, engine – ECU Horn, back-up alarm
Electrical cables, engine – ECU Horn, back-up alarm 347
Standard ECU assembly 349
Power converter module 351
Inclination sensor module 353
Inclination sensor module 355
Back-up alarm module 357
Back-up alarm module, Quacker 359
Bracket module 361
Cable harness kit Power supply cab
Cable harness kit Power supply cab 363
Driving & side direction lights, number plate light, option
Driving & side direction lights, number plate light, option 365
Steering column switch module 367
Cable harness kit 369
Registration plate light module 371
Registration plate light 373
Holder, Registration plate light 375
Reversing light, option
Reversing light module 377
DCA/GPS equipment module, option
DCA/GPS equipment module, option 379
Holder 381
GPS equipment module 383
GPS equipment assy 385
Computer 387
Tachograph, option
Tachograph, option 389
Holder assy 391
Power supply module 393
Speed sensor, frequency sensor, option
Speed sensor, frequency sensor, option 395
Pulse sensor module (6-pol) 397
Pre-heater installation, option
Pre-heater installation, option 399
Heater 401
Rotating beacon, working light, option
Rotating beacon, working light, option 403
Working light module H3 405
Rotating beacon module 407
Bracket, Rotating beacon 409
Cable harness, emergency steering, option
Cable harness, emergency steering, option 411
Displacement shift
Displacement shift 413
Compaction meter, option
Compaction meter, option 415
Power supply 417
External emergency stop, option
External emergency stop, option 419
Drivers platform
Platform, rops
Platform, rops 421
4812112278 Platform with 4-post ROPS
4812112278 Platform with 4-post ROPS 423
Basic kit Rops, roof, front handrail 425
Rear cover 427
Handrail 429
Cab, basic kit 431
Manual box 433
Decals basic kit 435
Cab symmetric module
Cab symmetric module 437
4812119366 Cab, cpl Comfort
4812119366 Cab, cpl Comfort 439
Screens 441
4812115202 Cab door, cpl
4812115202 Cab door, cpl 443
4812115200 Sliding screen, left hand 445
Windshield wiper 447
Roof 449
Heater assy 451
Hose kit heater 453
Cab Interior
Cab Interior 455
Heater controls 457
Cab cable harness 459
Cab, electrical equipment 461
Emergency hammer, hook 463
Cab, rear cover 465
Cab, front cover 467
Floor mat 469
Step light, front wiper switches 471
Cab, basic kit See page 431
Air channel 473
Sun-blind, inner light 475
4812119367 Cab, cpl Basic
4812119367 Cab, cpl Basic 477
Screens See page 441
4812115202 Cab door, cpl
4812115202 Cab door, cpl See page 443
4812115200 Sliding screen, left hand See page 445
Windshield wiper See page 447
Roof
Roof See page 449
Heater assy See page 451
Hose kit heater See page 453
Cab Interior
Cab Interior See page 455
Heater controls See page 457
Cab cable harness See page 459
Cab, electrical equipment See page 461
Emergency hammer, hook See page 463
Cab, rear cover 479
Cab, front cover 481
Wiper switch, front 483
Cab, basic kit See page 431
Manual box See page 433
Decals basic kit See page 435
Car stereo module, option 485
Heater hoses 487
Rear view mirror 489
Drivers seat
Drivers seat 491
Seat frame structure 493
4700391163 Steering column 495
Seat frame adapter module, rotating 497
Seat frame adapter module, fixed 499
Seat comfort, fabric suspensioned 501
Seat, galon suspensioned 503
Seat belts
Seat belt 2″ 505
Seat belt 3″ 507
Seat belt 2″ with reminder 509
Seat belt 3″ with reminder 511
Floor cassette module 513
Control module 515
Forward reverse control module 517
Display unit 521
Reading light 523
Control panel cover 525
Decals
Decals 527
Decals 531
Plain Dynapac decals, kit 533
Optional equipment
Strike off blade kit
Strike of blade kit 535
Hydraulic and Electrical kit 537
4812113498 Hydraulic valve, Strike-off blade 539
4812121948 Hydraulic cylinder 541
Strike off blade, mount 543
Locking device, module 545
Indicator, module 547
Fire extinguisher/First Aid Cushion
Fire extinguisher/First Aid Cushion 549
Fire extinguisher 551
Level sensor module, option
Level sensor module, option 553
SMV-sign
SMV-sign 555
Air conditioning
Air conditioning 557
Drying filter module 559
4812114257 Drying filter assy 561
Condensor assembly 563
ACC module 565
4812113624 ACC kit 567
AC module 569
4812113623 Evaporator, cpl 571
Hose kit AC 573
Compressor module 575
Hose assy kit for AC 577
Cooling box module
Cooling box module 579
Lunch box
Lunch box 581
Dyn@Link module 583
4812013038 GPS module 585
Compaction meter (DCM) 587
Dyn@lyzer 589
Appendix B:Parts Index 591
IMAGES PREVIEW OF THE MANUAL:
PLEASE NOTE:
- This is the same manual used by the dealers to diagnose and troubleshoot your vehicle
- You will be directed to the download page as soon as the purchase is completed. The whole payment and downloading process will take anywhere between 2-5 minutes
- Need any other service / repair / parts manual, please feel free to contact [email protected] . We still have 50,000 manuals unlisted
G.P
