Doosan DX140LC 3 Excavator Shop Manual – PDF DOWNLOAD
DESCRIPTION:
Doosan DX140LC 3 Excavator Shop Manual – PDF DOWNLOAD
Serial Number 50001 and Up (Europe Only)
April 2012
Only trained and authorized personnel should operate and maintain the machine. Follow all safety rules, regulations and instructions when operating or performing maintenance on machine.
• Do not operate machine if you are under the influence of drugs or alcohol. An operator who is taking prescription drugs must get medical advice to determine if he or she can safely operate a machine.
• When working with other personnel on a work site, be sure that all personnel know nature of work and understand all hand signals that are to be used.
• Be sure that all guards and shields are installed in their proper location. Have guards and shields repaired or replaced immediately if damaged.
• Be sure that you understand the use and maintenance of all safety features such as safety lock lever and seat belt. Use them properly.
• Never remove, modify or disable any safety features. Always keep them in good operating condition.
• Always check for and know the location of underground and overhead utility lines before excavating.
• Failure to use and maintain safety features according to instructions in this manual, Safety Manual and Shop Manual can result in death or serious injury. Know Your Machine Know how to operate your machine. Know the purpose of all controls, gauges, signals, indicators and monitor displays.
- Know the rated load capacity, speed range, braking and steering characteristics, turning radius and operating clearances. Keep in mind that rain, snow, ice, loose gravel, soft ground, slopes etc., can change operating capabilities of your machine.
- Proper Work Tools and Attachments Only use work tools and attachments that are recommended by DOOSAN for use on DOOSAN machines. When installing and using optional attachments, read instruction manual for attachment, and general information related to attachments in this manual. Because DOOSAN cannot anticipate, identify or test all attachments that owners may want to install on their machines, contact DOOSAN for written authorization and approval of attachments, and their compatibility with optional kits.
- Attachments and attachment control systems that are compatible with the machine are required for safe and reliable machine operation. Do not exceed maximum operating weight (machine weight plus attachment) that is listed on ROPS certification plate.
- Make sure that all guards and shields are in place on machine and on work tool. Depending on type or combination of work equipment, there is a potential that work equipment could interfere with the cabin or other parts of machine.
- Before using unfamiliar work equipment, check if there is any potential of interference, and operate with caution. While you are performing any maintenance, testing, or adjustments to attachments, stay clear of the following areas: cutting edges, pinch points, and crushing surfaces. Never use attachment as a work platform or manlift. Contact your DOOSAN distributor about auxiliary hydraulic kits for attachments installation.
- If you are in doubt about compatibility of a particular attachment with a machine, consult your DOOSAN distributor. Pressurized Fluids Pressurized air or fluids can cause debris and/or fluids to be blown out. This could result in death or serious injury. Immediately after operations are stopped, coolant, engine oil, and hydraulic oil are at their highest temperatures and the radiator and hydraulic tank are still under pressure. Always wait for temperature to cool down.
- Follow specified procedures when attempting to remove caps, drain oil or coolant, or replacing filters. Always wait for temperature to cool down, and follow specified procedures when performing these operations. Failure to do so can result in death or serious injury. When pressurized air and/or pressurized water is used for cleaning, wear protective clothing, protective shoes, and eye protection. Eye protection includes goggles or a protective face shield.
- Pressure can be trapped in a hydraulic system and must be relieved before maintenance is started. Releasing trapped pressure can cause sudden machine movement or attachment movement. Use caution if you disconnect hydraulic lines or fittings. High-pressure oil that is released can cause a hose to whip or oil to spray. Fluid penetration can result in death or serious injury. If fluid enters skin or eyes, get immediate medical attention from a physician familiar with this injury.
- Obey all local laws and regulations for disposal of liquids. To prevent hot coolant from spraying out, stop engine and wait for coolant to cool. Using gloves, slowly loosen cap to relieve pressure.
Doosan DX140LC 3 Excavator Shop Manual – PDF DOWNLOAD
Track Excavator Maintenance Safety …………………………………………… SP002322
Specifications
Specifications for DX140LC-3……………………………………………………… SP002509
General Maintenance
General Maintenance Instructions……………………………………………….. SP002454
Standard Torques……………………………………………………………………… SP002404
Upper Structure
Cabin ………………………………………………………………………………………. SP002324
Counterweight…………………………………………………………………………… SP002510
Fuel Tank…………………………………………………………………………………. SP002511
Fuel Transfer Pump (Option) ………………………………………………………. SP002546
Swing Bearing…………………………………………………………………………… SP002329
Swing Reduction Gear……………………………………………………………….. SP002526
Lower Structure and Chassis
Track Assembly ………………………………………………………………………… SP002512
Engine and Drivetrain
Engine Coolant Heater (Option) ………………………………………………….. SP002328
Drive Coupling (Main Pump)……………………………………………………….. SP002515
Hydraulics
Hydraulic System Troubleshooting, Testing and Adjustment …………… SP002538
Accumulator……………………………………………………………………………… SP002455
Center Joint (Swivel)………………………………………………………………….. SP002456
Swing Motor……………………………………………………………………………… SP002527
Travel Device……………………………………………………………………………. SP002516
Main Pump……………………………………………………………………………….. SP002517
Gear Pump ………………………………………………………………………………. SP002500
Main Control Valve ……………………………………………………………………. SP002528
Remote Control Valve (Work Lever / Joystick) ………………………………. SP002395
Travel Control Valve (with Damper)……………………………………………… SP002381
Solenoid Valve Assembly …………………………………………………………… SP002406
Breaker EPPR Valve (Option) …………………………………………………….. SP002458
Dozer Valve ……………………………………………………………………………… SP002529
Hydraulic Schematic (DX140LC-3)………………………………………………. SP002518
Electrical System
Electrical System ………………………………………………………………………. SP002337
Electrical Schematic ………………………………………………………………….. SP002508
Attachments
Boom and Arm………………………………………………………………………….. SP002513
Bucket……………………………………………………………………………………… SP002506
