DANA SPICER Axle 733-146 733-147 733-10078567 Service Manual – PDF DOWNLOAD
DESCRIPTION:
DANA SPICER Axle 733-146 733-147 733-10078567 Service Manual – PDF DOWNLOAD
INTRODUCTION
- The efficiency and continued operation of mechanical units depend on constant, correct maintenance and also on efficient repair work, should there be a break-down or malfunction. The instructions contained in this manual have been based on a complete overhaul of the unit. However, it is up to the mechanic to decide whether or not it
- is necessary to assemble only individual components, when partial repair work is needed. The manual provides a quick and sure guide which, with the use of photographs and diagrams illustrating the various phases of the operations, allows accurate work to be performed.All the information needed for correct disassembly, checks and
- assembly of each individual component is set out below. In order to remove the differential unit from the vehicle, the manuals provided by the vehicle manufacturer should be consulted. In describing the following operations it is presumed that the unit has already been removed from the vehicle.
IMPORTANT:
In order to facilitate work and protect both working surfaces and operators, it is advisable to use proper equipment such as: trestles or supporting benches, plastic or copper hammers, appropriate levers, pullers and specific spanners or wrenches. Before going on to disassemble the parts and drain the oil, it is best to thoroughly clean the unit, removing any encrusted or accumulated grease.
TABLE OF CONTENTS:
DANA SPICER Axle 733-146 733-147 733-10078567 Service Manual – PDF DOWNLOAD
CONTENTS
INTRODUCTION 5
VERSION TRACKING 6
MANUAL APPLICABILITY AND SUPPORTED MODELS 6
SPECIFICATIONS 7
DEFINITION OF VIEWPOINTS 7
DATA PLATE 7
CONVERSION TABLES 8
UNITS OF PRESSURE 8
UNIT OF WEIGHT 8
UNITS OF TORQUE 8
TORQUE SPECIFICATIONS 9
COARSE PITCH 9
FINE PITCH 9
WHEEL NUT TIGHTENING TORQUES 10
MAINTENANCE 11
MAINTENANCE POINTS 11
OIL DRAINING MANDATORY PROCEDURE 12
CENTRAL HOUSING 12
PLANETARY GEAR REDUCTION 12
END-STOP PLIER SETTING 13
RETAINING SNAP RING FOR BORES 13
RETAINING SNAP RING FOR SHAFTS 13
MAINTENANCE INTERVALS 14
LUBRICANT & SEALANT SPECIFICATIONS 15
SAFETY PRECAUTIONS 17
PLANETARY REDUCTION GEAR 19
EXPLODED VIEW 19
DISASSEMBLY 20
ASSEMBLY 26
STEERING SENSOR AND STEERING KNUCKLE ADJUSTMENT 31
EXPLODED VIEW 31
DISASSEMBLY 32
ASSEMBLY 35
STEERING CYLINDER 41
EXPLODED VIEW 41
DISASSEMBLY 42
ASSEMBLY 46
LIMITED SLIP DIFFERENTIAL UNIT 51
EXPLODED VIEW 51
DISASSEMBLY 52
INSTALL AND ADJUST 55
BEVEL PINION 61
EXPLODED VIEW 61
DISASSEMBLY 62
INSTALL AND ADJUST 64
SUSPENSION 69
EXPLODED VIEW 69
DISASSEMBLY 70
ASSEMBLY 73
SUSPENSION SENSOR 77
EXPLODED VIEW 77
DISASSEMBLY 78
ASSEMBLY 79
ADJUST 80
SUSPENSION SUPPORT 83
EXPLODED VIEW 83
DISASSEMBLY 84
ASSEMBLY 85
UPPER WISHBONE 87
EXPLODED VIEW 87
DISASSEMBLY 88
ASSEMBLY 91
LOWER WISHBONE 95
EXPLODED VIEW 95
DISASSEMBLY 96
ASSEMBLY 100
SUSPENSION PISTON 105
EXPLODED VIEW 105
DISASSEMBLY 106
ASSEMBLY 107
SPECIAL TOOLS 109
TOOL HANDLE 109
T1 109
T2 110
T3 111
T4 112
T5 113
T6 114
T7 115
T8 116
T9 117
T10 118
T11 118
T12 119
T13 120
T14 121
T15 121
T16 122
T17 123
T18 124
