Case IH Tractor SERVICE MANUAL 4206F 4206R 4208F 4208R 4212F 4212R 4406F 4406R 4408F 4408R
FILE DETAILS:
Case IH Tractor 4206F, 4206R, 4208F, 4208R, 4212F, 4212R, 4406F,4406R, 4408F, 4408R, 4412F, 4412R, 4416R Corn header Service Manual_47869954
Size : 43.5 MB
Format : PDF
Language : English
Number of Pages : 516 pages
Brand: Case IH
Type of machine: Tractor
Type of document: Service Manual
Model: 4206F, 4206R, 4208F, 4208R, 4212F, 4212R, 4406F,4406R, 4408F, 4408R, 4412F, 4412R, 4416R Corn header
Part No: 47869954
DESCRIPTION:
- All repair and maintenance work listed in this manual must be carried out only by qualified dealership personnel, strictly complying with the instructions given, and using, whenever possible, the special tools. Anyone who performs repair and maintenance operations without complying with the procedures provided herein shall be responsible for any subsequent damages.
- The manufacturer and all the organizations of its distribution chain, including – without limitation – national, regional, or local dealers, reject any responsibility for damages caused by parts and/or components not approved by the manufacturer, including those used for the servicing or repair of the product manufactured or marketed by the manufacturer.
- In any case, no warranty is given or attributed on the product manufactured or marketed by the manufacturer in case of damages caused by parts and/or components not approved by the manufacturer.
- The manufacturer reserves the right to make improvements in design and changes in specifications at any time without notice and without incurring any obligation to install them on units previously sold. Specifications, descriptions, and illustrative material herein are as accurate as known at time of publication but are subject to change without notice. In case of questions, refer to your CASE IH Sales and Service Networks. 47869954 04/05/2015 3
IMAGES:
VIDEO PREVIEW:
TABLE OF CONTENTS:
Case IH Tractor 4206F, 4206R, 4208F, 4208R, 4212F, 4212R, 4406F,4406R, 4408F, 4408R, 4412F, 4412R, 4416R Corn header Service Manual_47869954
INTRODUCTION
Hydraulic systems 35
[35 910] Head and header hydraulic drive 35 1
[35 603] Deck plate hydraulic system 35 2
[35 660] Flip-up header 35 3
[35 000] Hydraulic systems 35 4
Electrical systems 55
[55 000] Electrical system 55 1
[55 100] Harnesses and connectors 55 2
[55 421] Feeding control system 55 3
[55 408] Warning indicators, alarms, and instruments 55 4
Attachments/Headers 58
[58 130] Attachment/Header frame 58 1
[58 120] Attachment/Header feed auger 58 2
[58 220] Corn header structure 58 3
[58 218] Corn header feeder structure 58 4
[58 228] Rotating dividers 58 5
[58 230] Stalk choppers 58 6
[58 408] Row-independent header guards and protection 58 7
[58 414] Row-independent header gearboxes 58 8
[58 428] Row-independent header rotating dividers 58 9
[58 100] Attachment/Header support and drives 58 10
[58 208] Corn header shields and guards 58 11
[58 224] Header drive 58 12
Product feeding 60
[60 122] Length-of-cut gearbox
Foreword – Important notice regarding equipment servicing 3
Personal safety 4
Safety rules 7
Safety rules – Ecology and the environment 8
Safety signs – Rigid headers 9
Safety signs – Rigid 16–row headers 24
Safety signs – Folding headers 41
Basic instructions – Shop and assembly 55
Torque – Minimum tightening torques for normal assembly 57
Torque – Standard torque data for hydraulics 62
Basic instructions – Chain Wear Tables – Roller Chains 64
Attachments/Headers – Basic instructions 66
General specification 68
Capacities 72
Product identification 73
Product identification 74
Product identification – Machine orientation
