Case 1835 Uni-Loader Operators Manual 9-6832 – PDF DOWNLOAD
IMAGES PREVIEW OF THE MANUAL:
DESCRIPTION:
Case 1835 Uni-Loader Operators Manual 9-6832 – PDF DOWNLOAD
TO THE OWNER :
This manual is your guide to safe, efficient operation. Before you operate
this machine, read this manual.
When you get your new machine from your Case dealer, you will be
instructed about correct operation and maintenance as shown in the Owner
Warranty Registration form. When your Case dealer has given you these
instructions, put your signature on the report. Then he will give you a copy for
your records.
AFTER DELIVERY CHECK :
Three copies of the After Delivery Check are in the back of this manual.
One copy is for you, one copy is for the dealer and one copy is for the
Construction Equipment Service Department. Make sure that your Case
dealer does the After Delivery Check after the first 20 hours of machine
operation.
TABLE OF CONTENTS:
Case 1835 Uni-Loader Operators Manual 9-6832 – PDF DOWNLOAD
Introduction 2 Moving a Disabled Machine 57
To the Owner 2 Transporting the Machine 58
Delivery of the New Machine 3 Operating in Cold Temperatures 60
After Delivery Check 3 Operating in Hot Temperatures 60
Safety 4 Loader Operation 61
Safety Rules 4 Safety When You Operate 61
Spark Arrester Muffler 17 Filling the Bucket 62
Roll-Over Protective Structure 18 Tool-Tach 63
Location of Product Identification Backhoe Operation 65
Number (PIN) and Serial Numbers 21 Seat Adjustment 65
Specifications 23 Hydraulic Power 66
Diesel Engine 23 Backhoe Controls 67
Gasoline Engine 23 Engine Speed 67
Transmission 24 Before You Operate the Backhoe 68
Electrical System 24 Transport Position of the Backhoe 69
Capacities 24 Operating the Backhoe 68
Operating Weight 24 Lifting with the Backhoe 70
Dimensions 25 Procedure to Remove the Backhoe 71
Operating Data 27 Procedure to Install the Backhoe 73
Tires 27 Fuels and Lubricants 76
Loader Buckets 27 Diesel Fuel 76
Backhoe 28 Fuel Specifications 76
Operating Instructions 30 Gasoline 76
Instruments and Controls Fuel, Fluids and Lubricants Chart 77
(Fast Reference) 30 Maintenance and Lubrication 78
Warning Lamp Panel 32 Introduction 78
Instrument Panel 33 Maintenance Chart for First Period of
Controls 34 Operation with a New Machine 79
Restriction Indicator for Air Cleaner 36 Maintenance Chart for Regular
Restriction Indicator for Intervals 79
Hydraulic Filter 36 Safety Before Servicing 82
Sight Gauge for Hydraulic Oil Level 36 Procedure to Use the Safety Strut 83
Control Pedal for Front Procedure to Put the Safety Strut
Mounted Equipment 37 in Storage 84
Controls for Steering 38 Safety Decals on the Machine 85
Pivot Turn 39 Do Not Operate Tag 85
Gradual Turn 39 Grease Fittings 86
Counter-Rotation Turn 39 Engine Lubrication System 88
Control for Loader Lift Arm 40 Air Cleaner System 90
Control for Loader Bucket/Fork 41 Engine Cooling System 95
Controls for Backhoe 42 Diesel Fuel System 98
Operator’s Seat Belt 43 Gasoline Fuel System 104
Two Inch Belt 43 Electrical System 105
Three Inch Belt 44 Equipment Hydraulic/Hydrostatic
Engine Operation 45 Transmission System 112
First Period of Operation with Drive Chains 117
a New Engine 45 Drive Chain Compartment Oil 122
Service and Checks Before You Start 45 Drive Belt 123
Starting the Gasoline Engine 47 Maintenance of the Seat Belt 125
Starting the Diesel Engine 48 Spark Arrester Muffler 125
Engine Speed 48 Installing Wheels and Tires 126
Stopping the Engine 49 Procedure to Put the Machine
Methods to Help Start the Engine 49 in Storage 127
Machine Operation 56 Procedure to Remove the Machine
Starting 56 from Storage 129
Stopping 57 After Delivery Check 131
