AGCO® NA 8792 8776 Planter SERVICE MANUAL 79034268 B – PDF DOWNLOAD
FILE DETAILS:
AGCO® NA 8792 8776 Planter SERVICE MANUAL 79034268 B – PDF DOWNLOAD
Language : English
Pages : 539
Downloadable : Yes
File Type : PDF
Size:65.1 MB
DESCRIPTION:
AGCO® NA 8792 8776 Planter SERVICE MANUAL 79034268 B – PDF DOWNLOAD
GENERAL OPERATION AND SERVICE
Operating
• Read and understand all the operating and safety precautions before operating machinery.
• In addition to equipment configuration and design, hazard control and accident prevention depend on awareness, concern, prudence and proper training of personnel in the operation, maintenance, transport and storage of equipment.
• Always raise implement, shut off tractor engine, set the parking brake, shift to park position (or neutral) remove the key and install cylinder lockup channels before working around the machine.
• Avoid working under the planter. However, if it becomes unavoidable to do so, make sure planter is securely blocked and cylinder lockup channels are in place.
• Do not attempt to lubricate or adjust planter while the machine is in operation.
• Machinery operation must be performed only by persons who are responsible and delegated to do so.
• Only the operator must be permitted on the tractor (unless tractor has a factory-installed instructor seat) when tractor and planter are moving. Never permit anyone to ride on the planter.
• Avoid wearing loose-fitting clothing and jewelry. Always tie up long hair that can be caught in moving parts.
• Wear personal protective equipment (PPE) such as, but not limited to, protection for the eyes, lungs, ears, head, hands and feet when operating, servicing or repairing equipment.
• Make sure bystanders are clear before operating tractor or machine.
• Do not leave the tractor or implement unattended with the engine running.
• Never attempt to operate the planter unless seated in the operator’s seat on the tractor. 79034268 B Rev. Safety
• Tractor must be equipped with a rollover protective structure (ROPS), and a seat belt. Use seat belt during operation.
• Make sure the tractor is in good operating condition, and has adequate braking capabilities.
• Do not dismount from the moving tractor. • Regulate ground speed to field conditions, and maintain control at all times
. • Watch for overhead wires or other obstructions when raising markers, and when moving planter with marker(s) raised.
• Disconnect and store the planter where children do not normally play. Stabilize the planter by using suitable supports, and block the wheels. • Always lower planter when not in use and relieve pressure in the hoses and cylinders.
• Do not allow children to ride on, play on, or operate equipment. Always keep children away from equipment operating, servicing, and storage areas.
• Do not stand between tractor and planter to install hitch pin when tractor engine is running.
