1969 Chevrolet Heavy Duty Truck 70 80 Series shop Manual – PDF DOWNLOAD
Video Preview:
Image Preview:
Description:
1969 Chevrolet Heavy Duty Truck 70 80 Series shop Manual – PDF DOWNLOAD
- This manual contains, in separate Service and Overhaul sections, procedures for maintenance adjustments, minor service operations, and replacement of components (Service) and for disassembly and assembly of major components (Overhaul) for Chevrolet Series 70 and 80 Heavy Duty Trucks.
- CHASSIS SERVICE SECTION The Service Section of this manual includes procedures for maintenance and adjustments, minor service operations, and removal and installation of components.
- The Index on this page enables the user to quickly locate any desired section in the Service Section. At the beginning of each individual section containing more than one major subject is a Table of Contents, which gives the page number on which each major subject begins.
- An Index is placed at the beginning of each major subject within the section. A summary of Special Tools will be found following Section 9 of the Overhaul portion of this manual while Specifications covering vehicle components are presented at the end of each section.
- This manual should be kept in a handy place for ready reference. If properly used, it will enable the technician to better serve the owners of Chevrolet vehicles. All information, illustrations and specifications contained in this literature are based on the latest product information available at the time of publication approval.
- The right is reserved to make changes at any time without notice.
Table Of Contents:
1969 Chevrolet Heavy Duty Truck 70 80 Series shop Manual – PDF DOWNLOAD
Subject Page No.
Lubrication Charts
Conventional Cab Models . . ………………… 2
Tilt Cab Models………………………………….. 4
Tandem Bevel A x l e s …………………………… 6
Engine and Accessories………………………. 7
Capacities
Crankcase …………………………………………. 8
Transmission ………………………………….. 8
Rear Axles ………………………………………. 8
Engine Oil – Symbol “E ” ………………………. 8
Engine Oil Recommendation ………………….. 8
Viscosities …………………………………………… 9
Checking Engine Oil Level …………………….. 9
Engine Oil Filter ………………………………….. 10
Air Cleaners
Carburetor Air Cleaner ……………………. 11
Tractor Type Air C le a n e r ………………….. 11
Brake Power and Axle Cyl. Air Cleaner. . 11
Air Compressor Air Strainer……………… 11
Other Engine Oil U s e s …………………………… 12
Crankcase Ventilation …………………………… 13
Crankcase Breather……………………………….. 14
Multi-Purpose Gear Lubricant – Symbol “MP” 14
Viscosities …………………………………………… 15
Rear Axle ……………………………………………… 15
Transmission…………………………………………. 16
Universal Joints…………………………………….. 16
Chassis Lubricant – Symbol ” C ” ……………… 17
High Temperature Grease – Symbol ”S2” . . 17
Wheel Bearings………………………………………. 17
Other High Temperature Grease Uses . . . . 17
Petroleum Jelly – Symbol “S3” ……………… 17
Distributor Breaker Cam ………………………. 17
Battery Terminals………………………………….. 17
Waterproof Grease – Symbol “S4” …………. 18
Refrigerant Machine Oil – Symbol “S7” . . . 18
Axle Shift Unit – Electric………………………. 18
Hydraulic Brake Fluid – Symbol “S12” . . . 18
Special Grease – Symbol “S 1 7 ” ………………… 18
Type A Fluid – Symbol ” S 1 9 ” ………………….. 18
Power Steering System…………………………… 18
High Temperature Grease (Special)
– Symbol “S27” …………………………………….. 19
Clutch Release Bearing…………………………… 19
High Temperature Grease (Special)
– Symbol “S 2 8 ” …………………………………….. 19
Stopmaster Brake U n i t …………………………… 19
